1.2 MWh Photovoltaic Containerized Energy Storage System 6000 Cycles Lifetime

Ask Lasest Price
Brand Name :	HUAXING
Model Number :	600kWp-500kW-1.2MWH
Certification :	MSDS
Price :	Nigotiation
Payment Terms :	T/T, L/C
Supply Ability :	10000pcs per month
Delivery Time :	30 days

Add to Cart

Product Details
Company Profile

1.2 MWh Photovoltaic Containerized Energy Storage System 6000 Cycles Lifetime

1.2 MWh Photovoltaic Containerized Energy Storage System

Product Characteristics

Flexible Configuration

Supports multiple sets of parallel use
Supports simultaneous access to grid/diesel, PV, and batteries

Easy Installation

Easy on-site construction with one-piece transportation
IP55 protection class, meet the outdoor installation conditions

Smart and User-Friendly

Seamless switching between parallel and off-grid states for uninterrupted supply of loads
Built-in EMS with multiple operating mode options for increased profitability

Safe and Reliable

Redundant design for critical functions
Efficient thermal management design and active fire protection system for system safety

Battery Parameters

Product model	BATT-GS-500/1000-T	BATT-GS-500/1200-T
Cell Type	LFP,3.2V314Ah	LFP,3.2V314AhLFP,3.2V314Ah
Battery Module	64V280Ah,17.92kWh,130kg	64V314Ah,20.09kWh,130kg
Number of Battery Module	60PCS	60PCS
Rated Energy	1075KWh	1205KWh
Rated Voltage	768V	768V
Voltage Range	696.0-852.0V(Cell:2.9-3.55Vdc)	696.0-852.0V(Cell:2.9-3.55Vdc)
Charge and Discharge Rate	≤0.5C	≤0.5C
DOD	95%	95%
Lifetime	over 6000 cycles	over 6000 cycles
Cooling Method	Air conditioning with forced air cooling	Air conditioning with forced air cooling
Fire Protection System	Aerosol/five-in-one detector + fire host + heptafluoropropane / perfluorohexanone fire suppressor	Aerosol/five-in-one detector + fire host + heptafluoropropane / perfluorohexanone fire suppressor

PCS Parameters

Rated Power	500KVA
Rated Voltage	400Vac
Rated Current	722A
Rated Grid Voltage	400Vac
Rated Frequency	50/60Hz
THDi	＜3%
THDu	<1%linear;<5%nonlinearity
Overload Capacity	10% Long-term operation
Isolation Method	Transfommer isolation
Maximum Photovoltaic Input Voltage Maximum Photovoltaic Input Voltag	1000Vdc
Maximum Photovoltaic Power	600/660/720kw
MPPT Operating Voltage Range	250-850Vdc
MPPT Full-load Voltage Range	450-850Vdc
Communication Interface	R5485/Ethernet/CAN
Communication Protocol	ModbusRTU, ModbusTC

System Parameter

Communication Interface(EMS)	R5485/Ethernet
Installation Location	Outdoor installation
IP Grade	IP55
Corrosion-proof Grade	C5
Operating Humidity Range Operating Humidity Range	0~95%(noncondensing)
Operating Temperature Range	-30°C-+55°C
Maximum Working Altitude	5000m(>3000m derating)
Dimensions(LWH)	605824382591mm
Weight	about 19T

Application scenarios

Photovoltaic container energy storage is widely used in remote areas that lack grid coverage, fields such as mines and oil brick Wells, backup power supply for large equipment, emergency power supply when natural disasters occur, and so on.

Operating Principle

Energy storage systems, such as lithium-ion batteries, are able to store the electricity generated by photovoltaic power and release it when needed. This solves the problem of discontinuous solar power generation, making it possible to provide electricity continuously during rainy weather or at night.
