Product Description
Advantages:
1.This 24V10Ah LFP battery system has built-in BMS and stainless
steel box painted in
black or white. 1. Maintenance free. Modular design for easy
installation and capacity expansion.
2. Long cycle life (more than 3000 cycles at 80% DOD)
3. Bulit-in smart BMS with multiple protection and communication
functions
4. Wide working temperature range and high reliability
5. Multiple battery units can be connected in parallel,suitable for
high energy storage applications.
6. Compatible with various charge controllers and inverters
7. Widely used for off-grid solar system storage, telecom back-up,
central data center...etc.
Basic specification:
Item | Specification | Remark |
Nominal Voltage | 25.6V | |
Nominal Capacity | 10AH | |
OEM | Yes | |
| ODM | Yes | |
Charging Current | 0.5~1C | |
| 14.6V | |
Charging Method | CC/CV | |
Max. Continuous Discharging Current | 1C | |
End-of-discharge Voltage | 8V | |
| Max. Pulse Discharging Current | 2C | |
Cycle Life | ≥2000 cycles | |
Operating Temperature Range | Charging Temperature: 0~60 °C Discharging Temperature: -20~ 60°C Storage Temperature:-20~ 45°C | |
Appearance: Without break, scratch, distortion, contamination, leakage and so
on.
Main Applications:- RV ,Motorhome,Electric two-wheeled vehicle, three-wheeled vehicle,
four-wheeled low-speed vehicle, scooter, golf cart, security golf cart,forklift and so on.
- Telecommunication, back-up power supply, UPS
- Storage energy for solar system, solar street, home energy storage
and so on
Company Profile
Hunan Huaxing New Energy Technology Co.,Ltd is R&D production
and sales of 32700 LiFePo4 cells and battery pack.
Our company passed ISO9001:2015 and iSO14001:2015 and ISO45001:2018
Our 32700 LFP cell passed
UL1642/IEC62619/IEC61960/IEC62133/CE/PSE/BIS/Rohs/UN38.8 and MSDS.
Cell packaging:
