Diy Any Voltage And Capacity Lifepo4 Battery Pack 9.6V 12AH 3S2P
For Solar Street Light Product Description:
Our 9.6V 6AH LiFePO4 Battery Pack is a rechargeable lithium-ferrous-phosphate (LFP) battery pack
designed to meet the needs of applications requiring high energy
density and long cycle life. This LFP battery pack consists of a
combination of cells in series and/or parallel configuration, and
is built with a unique battery management system to ensure safety
and performance. It has a remarkable cycle life of up to 2000 times
and can operate in temperatures ranging from -20℃ to 60℃. Despite
its high energy density, this LFP battery pack is lightweight with
a weight of only 0.9kg. It is also capable of providing a maximum
discharge current of 3A and a maximum charge current of 3A.
Lifepo4 Battery Pack 9.6V 12AH 3S2P For Solar Street Light
Features:
- LiFePO4 Battery Pack: A rechargeable battery pack with high energy density.
- Size: 200*35*75mm, suitable for a variety of applications.
- Cycle Life: Can be cycled up to 2000 times for long-term use.
- Self-discharge Rate: ≤3%/month, low self-discharge rate for better performance.
- Storage Temperature: -20~45℃, suitable for a wide range of temperature conditions.
Lifepo4 Battery Pack 9.6V 12AH 3S2P For Solar Street Light
Technical Parameters:
| Parameter | Value |
|---|
| Type | LiFePO4 Battery Pack |
| Max. Charge Current | 3A |
| Cycle Life | 2000 Times |
| Voltage | 9.6V |
| Operating Temperature | -20~60℃ |
| Product Name | LiFePO4 Battery Pack |
| Capacity | 12Ah |
| Weight | 0.9kg |
| Self-discharge Rate | ≤3%/month |
| Max. Discharge Current | 3A |
| Discharge Temperature | -20~60℃ |
Lifepo4 Battery Pack 9.6V 12AH 3S2P For Solar Street Light
Applications:
Huaxing LiFePO4 Battery Pack
Huaxing LiFePO4 Battery Pack, also known as Lithium Ion Phosphate
Battery Pack, is a cutting-edge energy storage solution with
superior performance and safety. It is certified with CE,
guaranteeing the highest quality standards. The model number is
HX-SOL-9.6/12.
The Huaxing LiFePO4 Battery Pack is an ideal solution for those
looking for a reliable and convenient energy storage solution. With
its superior performance and safety, it is the perfect choice for a
wide range of applications as below:
- Portable pull speaker,Solar Garden and Street Light,portable power
supply
- Home LED light,Solar Bus and Taxi Station Light,Solar Advertisement
LED Light,Solar Traffic Light
Customization:
LiFePO4 Battery Pack
Brand Name: Huaxing
Model Number: HX-SOL-9.6/12
Features:
- Place of Origin: Shenzhen,Guangdong
- Certification: CE
- Minimum Order Quantity: 50
- Price: Negotiation
- Packaging Details: 20 pcs per carton
- Delivery Time: 15 days
- Payment Terms: 30% Deposit,70% before balance payment
- Supply Ability: 3Gwh
- Discharge Temperature: -20~60℃
- Max. Charge Current: 3A
- Operating Temperature: -20~60℃
- Storage Temperature: -20~45℃
- Self-discharge Rate: ≤3%/month
Lithium-Ion-Ferrous-Phosphate-Battery,
Lithium-Ion-Phosphate-Battery-Pack,
Lithium-Ferrous-Phosphate-Battery-Pack
Packing and Shipping:
LiFePO4 Battery Pack Packaging and Shipping:
The LiFePO4 Battery Pack is packaged securely and safely in a
cardboard box or similar container. The box is designed to protect
the battery from shocks, vibrations, and other hazards during
shipping. The box should be clearly labeled with the manufacturer's
name, the product name, the safety warnings, and other relevant
information. The box should also include an instruction manual and
warranty information. The battery should be securely fastened
inside the box, and the box should be sealed with a strong
adhesive.
The LiFePO4 Battery Pack should be shipped in accordance with
shipping regulations and using the appropriate shipping method. The
package should be clearly labeled with the shipping address, the
destination address, and a warning about the contents of the
package. The package should also include a tracking number and any
other necessary information.
| DESCRIPTION | QUANTITY/CTN | PACKAGE | GROSS WEIGHT | NET WEIGHT | DIMS(m3) |
| (PCS) | CARTONS SIZE(MM) | (KG) | (KG) |
| 9.6V12AH LiFePo4 Battery | 20 | 420*245*180 | 17 | 16 | 0.02 |
